9sunsolar ground mount solar brackets structure pv panel mounting rack for brackets system solar array ground mount system
- 9sunsolar
- Fujian, China
- 10days（≤5MW）
- 1.6GW per year
The Aluminum Solar PV Panel Ground Mounting Racking System is a meticulously engineered solution tailored for the safe and efficient installation of solar panels on ground surfaces. Constructed from high-strength, premium-grade aluminum, this system ensures exceptional durability and supports adjustable tilt angles ranging from 0 to 60 degrees, providing versatile installation options. Designed to withstand extreme conditions, it can endure wind speeds of up to 130 mph (60 m/s) and heavy snow loads up to 30 psf (1.4 kN/m²), making it a dependable choice for a wide range of environmental challenges.
Description:
The steel solar Mounting System is a very economical solution with strong strength, it is very suitable for large projects and large PV power plant, especially for customers which are cost sensitive. Main parts of this solar structures are made of hot-dip galvanized steel, with good performance of structure strength, stability and anti-corrosion. Moreover steel mounting system have good performance in bearing strong wind load and heavy snow load.
Design Standard | JIS C 8955:2017 & AS/NZS1170 & DIM1055 |
Tilt Angle | 0-45 degrees |
Design Wind Load | < 60 m/s |
Design Snow Load | < 1.4 KN/m2 |
Main Material | Galvanized Steel |
Fixed Base | C pile |
Panel Orientation | Horizontal/Vertical |
● Reliability& Saving material
Professional design and Strict strength calculation, ensure that the mounting system can withstand the extreme weather condition and be the most economical as well.
● Fast production
Our factory has advanced production equipment, has more than one production lines, production time is guaranteed.
● Long service life
10 years of warranty and working life as long as 25 years.
●Customizable
Our designer group with rich experience can provide customers with professional solution to meet their requirements.
Packaging:
Factory:
Certificate:
Exhibition:
